Tenda SE105 5-port 2.5GbE Fanless Switch Review

Quick take
The Tenda SE105 is a budget-friendly, fanless 5-port 2.5GbE switch that’s effectively a twin of the BrosTrend S2. Internally, both share the same PCB (10056368 V1.1) and likely the same MaxLinear switch silicon under a non-removable heatsink. If you’re shopping, pick the one with the better price or availability—the experience should be nearly identical.

Highlights

• Ports and layout: Five 2.5GbE ports on the front, plus a 12V DC input; nothing on the rear.
• Fanless and quiet: Passive cooling with vents on the sides, top, and bottom.
• Enclosure and build: Snap-together plastic shell with plastic feet and bottom mounting points—clear cost optimizations versus metal-case competitors.
• Indicators: Status LEDs are on the top panel.
• Cosmetic difference vs BrosTrend S2: Lacks the large “2.5 Gbps” label on the front; otherwise nearly the same externally.

Inside the box

• PCB: Marked 10056368 V1.1—the same board seen in the BrosTrend S2.
• Switch chip: Heatsink isn’t removable, but design suggests a MaxLinear-based platform.
• Expandability hints: Unpopulated pads indicate an 8-port variant exists for this design.

Value and positioning

• Pricing note: At the time of testing, the Tenda SE105 cost around $10 more than the BrosTrend S2 reviewed earlier. Given the identical internals, your best pick is usually the cheaper one on sale.
• Ideal use cases: Home labs, small offices, and anyone upgrading to multi-gig without adding fan noise.

Bottom line
The Tenda SE105 delivers a simple, silent, and compact 2.5GbE upgrade path. Because it’s essentially the same hardware as the BrosTrend S2, let price, warranty, or brand preference guide your choice.
